Ubiquitous Medical Information

I-VIEW100

The I-VIEW100® is an AI-equipped automatic fundus camera that makes it easy for non-Ophthalmologists to take fundus shots and displays the risk of glaucoma, diabetic retinopathy, and macular degeneration within a second of fundus imaging.

Characteristic

  • Auto Shooting Mode : Auto Tracking, Auto Focusing, Auto Shot for Quick and Easy Image Acquisition
  • Equipped with AI Algorithm : First screening for three major blindness diseases
  • COMPACT volume.
http://umivision.co.kr/wp-content/uploads/2021/12/VIEW100-1.jpg
http://umivision.co.kr/wp-content/uploads/2021/12/VIEW100_left-1.jpg
http://umivision.co.kr/wp-content/uploads/2021/12/VIEW100_right-1.jpg

How to use it

So simple to use!

With clinics getting busier these days it was seen as crucial that the new TRC-NW8 should be the easiest camera to use in order to obtain the best possible results time after time.
To facilitate this new TRC-NW8 incorporates some ground breaking technology to aid the photographer

Easy aligment, Auto Focus and Auto shoot

Alignment could not be operator is still in control; however with the very latest in alignment aids the process of getting a sharp focussed image time after time could not be easier.

http://umivision.co.kr/wp-content/uploads/2021/12/정상안저.jpg

Auto Focus

This is a new feature of the TRC-NW8 which allows the operator to choose to have Auto Focus facility. This can be of great help when trying to photograph difficult subjects or patients with high degree of accommodstion.
Auto Focus allows for a sharp image every time.

http://umivision.co.kr/wp-content/uploads/2021/12/정상안저.jpg

Auto Shoot

The TRC-NW8 has the option for Auto Shoot which is of great benefit to the operator as it monitors when all parameters are correct and takes the picture.
This rapidly speeds up capture process and is of great benefit when photographing patients who have problems fixating.

How It Works (AI)

I-VIEW100®


http://umivision.co.kr/wp-content/uploads/2021/12/VIEW100_eye.jpg

Specification

Manufacturer UMI OPTICS
Model Fundus camera, I-VIEW100
Class and Type Class1 ClassB
Product Size 380(W) × 450(D) × 400(H)mm
Weight 16kg
Input Voltage and Frequency 100-240VAC 50/60Hz
Power Consumption 25 – 50VA
Resolution Center: 60line pairs/mm or more
Middle: 40line pairs/mm or more
Surroundings: 25line pairs/mm or more
Camera Resolution 13Mega Pixel, Color
Angle of View 45˚±5%
Light Source Nir: 830 nm ± 5%
White: 400 nm ~ 700 nm
LCD 7”Touch color LCD
Fuse T1.6AL250V
